E15 Defrost Control – Product Overview
The Type E15 Defrost Control is designed to manage frost removal from the outdoor coil of central systems and window unit heat pumps. It features a temperature-sensing bulb with capillary tubing, a timer motor, and a switch mechanism. The remote bulb monitors the outdoor coil temperature, while the timer permits defrost cycles only at pre-set intervals. The internal switch then activates the system’s defrost functions accordingly.

Technical Specifications – Type E15 Defrost Control

Capillary Length: 1200 mm

Contact Close (Temperature Fall): 2–10 °C or 2–3 °C (depending on model)

Temperature Cut-In: 3.9 °C

Temperature Cut-Out: -6.1 °C

Electrical Rating: 240 VAC
