Substitute for R13B1 in low temperature applications
Near azeotropic refrigerant containing R32 and R125
Distinct higher efficiency in comparison with R22
Significant higher pressure than R22
Pressure: 38.5 bar at a condensing templ of 60oC
Regarding the system components (compressor etc.), the higher pressure level of R410A has to be considered.
Non-flammable
R410A is being favoured worldwide as long-term alternative for R22
Compressors must be charged with polyol ester oils
Applications:
Air Conditioning Units
Heat Pumps
Cold Storage
Industrial and Commercial Refrigeration
Physical Properties:
Chemical Name: Difluoromethane/Pentafluoroethane R32/R125
Molecular Weight: 72.6 kg/kmol
Boiling Point at 1.013 bar: -51.5oC
Critical Temperature: 71.8oC
Critical Pressure: 48.9 bar
Density Liquid at 25oC: 1068 kg/m3
Lubricant: Polyol Ester
